The TM-WB allows teachers to engage with their audience in a more interactive way by lowering the whiteboard to the student’s height. It is a totally universal wall mount for whiteboards and short-throw projectors. Because the weight is carried by two floor-standing legs this stand is simpler and safer to install.
Applications are not just limited to interactive whiteboards; any flat-panel wider than 1050mm (41.34?) can be accommodated.
Adjustable Whiteboard Clamps
Adjustable arms attach to any board. All sizes from 57” or larger, with a thickness of 28-78mm (1.1-3.07?) can be fitted. The arms allow up/down and side-to-side adjustment of the board in relation to the projector.
Two 1.2m tall legs are attached to the wall, then the wall frame assembly is hung on the legs and locked in place. Cables can be routed to the floor through legs.
An alternative portable version has four large castors and comes with counter weights and locking feet for stability.
Maximum and minimum installation height is determined by the size of the whiteboard and the projector. Warning! In the lowest position the boom and projector can present a head height hazard
A high quality linear-drive motor drives the board and projector up and down. These motors are quiet, precise and rated for 12,000 cycles.
Activation is by a cable remote control.
The1.5m boom is fabricated from lightweight aluminium to reduce load on the wall mount. It has a range of 800-1500mm (31.5 – 59.1?). Can be cut shorter for ultra-short-throw projectors.
The TM-WB is designed to take the weight of interactive whiteboards and touch-panel LCDs up to 50kg (110.23 lbs). The boom can take projectors up to 10kg (22.05 lbs).
The portable versions includes a rotating mechanism so the boom can swing 90 degrees to fit through doors.
TM-WBP: 1300 x 1230 x 1050/772 mm (51.18? x 48.43? x 41.34?/30.4?) (height x width x depth with/without stabiliser down)
TM-WB: 1200 x 1100 x 140 mm / 47.24? x 43.31? x 5.51?
TM-WBP: 1200 x 1100 x 250 mm / 47.24? x 43.31? x 9.84?
TM-WB: 40.5 kg / 89.3 lbs
TM-WBP: 88 kg / 194 lbs
TM-WB: 45 kg / 99.21 lbs
TM-WBP: 95 kg / 209.44 lbs
SAFE WORKING LOAD:
Interactive Whiteboard / Touch-panel LCD: 50 kg / 110.23 lbs
Projector: 10 kg / 22.05 lbs
CONTRUCTION MATERIAL: Aluminium and Steel
COLOUR: White and Aluminium
Motor Type: Linear-drive
Rated Cycles: 12000
Pushing Force: 2000N
Pulling Force: 1800N
